Luna

Adopts the industry-leading platform Hisilicon Boudica150

Domestic design, built-in national cipher security chip, supports a variety of security encryption algorithm

Multiple application scenarios. Meet the needs of users for various types of IoT applications

Product Highlights

01
Domestic design, built-in national secret security chip, supports a variety of security encryption algorithm
02
Provides a good secondary development software and hardware environment
03
Supports dual-mode. Uses unique NB IOT Stand Alone main control mode to save plug-in MCU resources
04
supports HUAWEI Lite OS operating system with lightweight kernel
05
Supports a variety of NB-loT antennas, convenient for users in different application environments
06
Multiple application scenarios can meet the multi needs of IoT applications of users

Configurations	Parameter
SDRAM	64KB
Flash	352KB
Supported Communication Mode	China Mobile ；China Unicom ；China Telecom ；European / Southeast Asian ISP
Psec Encryption	Uses SM1, SM4, SM6, SM2, SM3 and other national cipher algorithms; and supports 3DES, AES, RSA1024/RSA2048，SHA256 and other commonly used international cipher algorithms
Power Supply	5V/2A via MicroUSB / 2 Pin battery Connector
40 pin expansion interface (space: 2.0 mm)	32 * GPIOs, UART，I2C，SPI，PWM
30 pin expansion interface (spacing: 2.0 mm)	8 * GPIOs, UART，I2C，SPI，PWM，ADC
Antenna	On board ceramic antenna / SMA jack
Other Items	JTAG(10Pin)2； SIM Card Slot 1；e-SIM；Micro USB*2；Key；LED
