Uranus

Uranus open source IOT hardware platform

Low-power consumption IoT devices for easy deployment and management

Product Highlights

01
1M on-chip storage, 4M on-board storage
02
Supports low power Wi-Fi, integrated FT2232D debugging chip and 40pin 96Boards general expansion Interface
03
Different types of sensors with various interfaces can be connected , and supports data collection and processing at board end and cloud reporting
04
Conform to industry standard

Configurations	Parameters
SoC	TICC3220 microcontroller
CPU	Cortex-M4
Clock Speed	80MHz
RAM	256KB
Storage	1024KB on-board Flash
Battery	On-board battery connector and charger
Debugger	FT2232D on-board JTAG and UART debugger
Wireless	TI CC3220 Wi-Fi Module
Connectors	FT2232D JTAG UART debug
Expansion Interface	40 pin Low Speed Expansion
Digitial Output	1.8V
Analog Input	0V-1.8V
Antenna	On-board chip antenna
Power Source	MicroUSB
OS Support	TI-RTOS /FreeRTOS / Zephyr
Size	60*30mm

Please feel free to contact us about product selection, technical support and media cooperation.
