| Configuration | Parameter |
| SoC | Hi3861V100 |
| CPU | 32bit / 160MHz operating frequency |
| RAM | 352KB |
| ROM | 288KB+2MB Flash |
| Wireless | 2.4GHz Wi-Fi, supports IEEE 802.11 b/g/n protocol |
| OS | HarmonyOS |
| Size | 64.2mm×23.5mm×78mm |
| CPU Subsystem | 32bit/160MHz operating frequency Embedded 352KB SRAM、288KB ROM及2MB Flash |
| Wireline | 2.4GHz Wi-Fi，supports IEEE 802.11 b/g/n protocol 2.4G/5dB Gain/1.5 m/SMA head sucker antenna |
| Temperature Acquisition | 2 channels, imported chip DS18B20 / 2m acquisition distance High quality stainless steel tube package, waterproof, moisture-proof, anti rust 9-12 bit adjustable resolution Temperature measurement range: - 55 ℃ ~ + 125 ℃ (lead temperature 85 ℃) The probe supports the protection of IP64 and above |
Temperature and Humidity Collection | 2-channel I2C bus, 3M acquisition distance Temperature measurement range: -40℃-125℃, accuracy: < 0.5 ℃ (typ. 0-6℃ ± 0.3℃) Humidity measurement range: 0-100% RH accuracy: ± 2-3% RH The probe supports the protection of IP64 and above |
| RS485 Bus | Pluggable screw free Phoenix terminal interface A. B bus for parameter configuration |
| Buttons | Power on reset button System reset button User button |
| Indicator | Product status indicator |
| Power Supply | Input range of 5V ~ 36V DC wide voltage power supply Compatible with dc-005 5.5 * 2.5 high temperature resistant power supply socket and pluggable screw free Phoenix terminal Equipped with 12V / 1A power adapter, 5525 power socket, 1m wire length |
| Size | Industrial extruded aluminum alloy shell 64.2mm × 23.5mm × 78mm Surface sandblasting oxidation Laser Mark |
